1606-XLE480EP FUENTE DE ALIMENTACION 480W 24VDC 20A ALLEN BRADLEY
Allen Bradley
Este es un producto original de la marca. El producto viene con una garantía estándar de marca de 1 año por defectos de fábrica.
Referencia Interna :
1606-XLE480EPUnidad :
Unidades
100% original
Se aceptan devoluciones*
Envio gratis*
| Nominal value output voltage 1 | 24 V |
|---|---|
| Secondary voltage adjustable | True |
| Max. output current 1 | 20 A |
| Nominal value output current 1 | 20 A |
| Power output | 480 W |
| Voltage type of supply voltage | AC/DC |
| 1st secondary output voltage | 24 V |
| Rated supply voltage at AC 50 Hz | 100 V |
| Rated supply voltage at AC 60 Hz | 100 V |
| Rated supply voltage at DC | 110 V |
| Power reserves | 20 % |
| DC OK relay contact | True |
| Input inrush current limiter | Active |
| Power factor | 0.98 typical |
| Output current range | 20 to 17.1 A |
| External input fuse, min | B-10 A or C-10 A |
| Power losses | 22.1 W typical |
| Derating | 12 W/°C |
| Efficiency | 95.6 % typical |
| Input inrush current | 10 A/4.5 A |
| Output voltage stabilized | True |
| Rail mounting possible | True |
| Stabilized | True |
| Marca | Allen Bradley |
